Panel Surya CPS158M-180-18
| Spesifikasi Elektrikal Panel Surya TKDN Monocrystalline 180W | |
|---|---|
| Rate Maximum Power (Pmax/W) | 180W |
| Module Efficiency (%) | 18.20% |
| Open Circuit Voltage (Voc/V) | 24.2V |
| Short Circuit Current (lsc/A) | 9.79A |
| Voltage at Pmax (Vmp/V) | 19.5V |
| Current at Pmax (lmp/A) | 9.24A |
| Power Tolerance | ±3% |
| STC: lrradiance l000W/m² Cell Temperature 25°C AMl.5 | |
| Spesifikasi Mekaninal Panel Surya TKDN Monocrystalline 180W | ||
|---|---|---|
| Solar Cell (Type/Size) | Mono | |
| Solar Cells Number | 36 pcs (4*9) | |
| Dimension | 1480*670*30mm | |
| Weight | 10.5 Kg/Pcs | |
| Glass Type | 3.2mm High Transmits | |
| Frame | Aluminum alloy | |
| Junction Box | IP67, 2*bypass diode | |
| Cable | 4mm², (+)900mm/(-)900mm | |
| Connector | Original MC4/Compatible MC4 | |
| Mechanical Load | Front 5400PA/back 2400PA | |
