Sistem Monitoring Nirkabel (wireless) Kontroler (Controller) BSC-WL Series untuk lampu penerangan tenaga surya (Penerangan Jalan Umum Tenaga Surya – PJUTS) ini terintegrasi dengan driver lampu led dan sensor gelombang mikro (microwave sensor). Pengguna tidak hanya bisa mengontrol jenis baterei, voltase pengisian baterei, waktu dan tingkat pencahayaan lampu melalui pengendali (remote control) kontroler.
Langkah-langkah koneksi
Dengan sistem monitoring ini, pengguna bisa mengatur parameter lanjutan melalui software PC atau laptop dan melalui APP. Sistem ini juga dilengkapi dengan fungsi mematikan dan menyalakan kembali lampu tenaga surya 365 hari.
Kontrol melalui PC atau Laptop
Prinsip kerja Sistem Monitoring Bluesmart
Model
- BSC-WL-10A 12V24V auto, 30W/12V 60W/24V
- BSC-WL-15A 12V24V auto, 40W/12V 80W/24V
Fitur Sistem Monitoring Bluesmart
- Mengontrol lampu led, panel surya, baterei, alarm jika terjadi permasalahan dan mempelajari permasalahannya, dan lain-lain.
- Built in driver lampu led dengan efisiensi output 91%–96%
- Dengan sensor gelombang mikro (microwave sensor), bisa memprogram semua kontroler tenaga surya melalui satu pengendali (remote control).
- Proteksi kelistrikan yang melindungi dari overload, arus balik, hubungan arus pendek, dan perlindungan pengisian dan pengosongan baterei, dan lain-lain.
- Fungsi peredupan otomatis berdasarkan kapasitas baterei untuk memasikan lampu tetap bisa menyala di malam hari selama 365 hari.
- Bahan pelindung anti air (waterproof IP67), cocok untuk untuk lingkungan bertemperatur tinggi atau rendah.
- Adanya indikator yang menunjukkan status semua lampu tenaga surya.
- Cocok untuk semua jenis baterei (gel/AGM/li-ion/Lifepo4, atau baterei lainnya).
Spesifikasi
| Rated charge current | 10A |
| Rated load current | 30MA-2.7A(adjustable) |
| Rated load voltage | Battery voltage-60V(Automatically set-up) |
| Max. Output power | 30W/12V 60W/24V |
| LED constant current efficiency | ≥ 92.8% (typically 94.5%) 24V, system is available for 95.3% |
| System voltage | 12V； 24V/12V AUTO； |
| Solar PV input voltage | <50V |
| Solar PV power | 180W/12V; 360W/24V |
| Load loss | Normal mode ≤ 7 mA, power-saving mode ≤ 3.5 mA |
| Operating temperature | Industrial: -35 ℃ to +55 ℃ (suffix I); |
| Boosting voltage | 14.6V; × 2/24V (duration: 10min) (Adjustable) |
| Equalize voltage | 14.4V; × 2/24V(duration: 10min) |
| Float voltage | 13.6V; × 2/24V (Adjustable) |
| Charge return voltage | 13.2V; ×2/24V(Adjustable) |
| Temperature compensation | -4.5mv / ℃ / 2V |
| Under voltage warning voltage | 12.0V; ×2/24V |
| Over-discharge voltage | 11.1V ; × 2/24V(Adjustable) |
| Over-discharge voltage return | 12.6V ; ×2/24V(Adjustable) |
| Light control voltage | 5V (Adjustable) |
| Dimension/N.W | 133*74*26mm/0.36kg |
| Rated charge current | 15A |
| Rated load current | 30MA-2.7A(adjustable) |
| Rated load voltage | Battery voltage-60V(Automatically set-up) |
| Max. Output power | 40W/12V 70W/24V |
| LED constant current efficiency | ≥ 92.8% (typically 94.5%) 24V, system is available for 95.3% |
| System voltage | 12V； 24V/12V AUTO； |
| Solar PV input voltage | <50V |
| Solar PV power | 270W/12V; 540W/24V |
| Load loss | Normal mode ≤ 7 mA, power-saving mode ≤ 3.5 mA |
| Operating temperature | Industrial: -35 ℃ to +55 ℃ (suffix I); |
| Boosting voltage | 14.6V; × 2/24V (duration: 10min) (Adjustable) |
| Equalize voltage | 14.4V; × 2/24V(duration: 10min) |
| Float voltage | 13.6V; × 2/24V (Adjustable) |
| Charge return voltage | 13.2V; ×2/24V(Adjustable) |
| Temperature compensation | -4.5mv / ℃ / 2V |
| Under voltage warning voltage | 12.0V; ×2/24V |
| Over-discharge voltage | 11.1V ; × 2/24V(Adjustable) |
| Over-discharge voltage return | 12.6V ; ×2/24V(Adjustable) |
| Light control voltage | 5V (Adjustable) |
| Dimension/N.W | 133*74*26mm/0.36kg |
