Baterai Gel 150AH 12V produk VOZ ini ini adalah baterai bebas perawatan atau MF (Maintenance Free). Baterai gel ini cocok dipergunakan untuk kebutuhan sistem listrik tenaga surya seperti PLTS Off Grid. Baterai Gel 150AH 12V akan menyimpan energi listrik yang diterima panel surya dan bisa dimanfaatkan untuk memenuhi kebutuhan listrik peralatan elektronik yang kita miliki.
Baca juga >> Memilih Baterai untuk Panel Surya
Fitur Baterai
- Micro millimeter SiO2 and H2SO4 technology for efficient gas recombination of up to 99% and freedom from electrolyte maintenanceor water adding.
- Not restricted for air transport-complies with IATA/ICAO Special Provision A67.
- Can be mounted in any orientation.
- Computer designed lead,calcium tin alloy grid for high power density.
- Long service life,float or cyclic applications.
- Maintenance-free operation.
- Low self discharge.
Spesifikasi Baterai Gel 150AH 12V
| Nominal voltage | 12V |
| Number of cell | 6 |
| Length (mm/inch) | 484/19.07 |
| Width (mm/inch) | 171/6.74 |
| Height (mm/inch) | 241/9.5 |
| Total Height (mm/inch) | 241/9.5 |
| Approx.Weight (kg/lbs) | 41.5/91.49 |
Material
| Component | Raw material |
| Positive plate | Lead dioxide |
| Negative plate | Lead |
| Container | ABS |
| Cover | ABS |
| Safety valve | Rubber |
| Terminal | Copper |
| Separator | Fiberglass |
| Electrolyte | Colloidal Silicon |
Configuration
| Capacity 77°F (25°C) | 100 hours rate (1.8A 11.1V) | 180Ah |
| 20 hours rate (8.15A 10.5V) | 163Ah | |
| 10 hours rate (15A 10.5V) | 150Ah | |
| 1 hour rate (94A 9.6V) | 94Ah | |
| Internal Resistance | Full charged battery 77°F (25°C): 7m Ω | |
| Capacity affected by Temperature (20 hour rate) | 104°F (40°C) | 102% |
| 77°F (25°C) | 100% | |
| 32°F (10°C) | 85% | |
| 5°F (-15°C) | 65% | |
| Self-Discharge 68°F (20°C) | Capacity after 3 month storage | 90% |
| Capacity after 6 month storage | 80% | |
| Capacity after 12 month storage | 60% | |
| Max discharge current 77°F (25°C): 1000A(5S) | ||
| Charge (Constant Voltage) | Float: 13.6 to 13.8V/77°F (25°C) | |
| Cycle: 14.4 to 14.7V/77°F (25°C) | ||
| Max Current: 25A |
